Aftermarket Tennant 9015391 | Offboard Charger | 24V | 20 AMPs | SB50 Connector Red and Grey

Aftermarket Tennant 9015391 | Offboard Charger | 24V | 20 AMPs | SB50 Connector Red and Grey

Aftermarket Tennant 9015391 | Offboard Charger | 24V | 20 AMPs | SB50 Connector Red and Grey

Aftermarket Tennant 9015391 | Offboard Charger | 24V | 20 AMPs | SB50 Connector Red and Grey

Aftermarket Tennant 9015391 | Offboard Charger | 24V | 20 AMPs | SB50 Connector Red and Grey

$479.00

Machine Fitment

Tennant T500/T500e
Nobles Speed Scrub SS500
Tennant S880
Tennant T380

Item Number Matches

Description

Description

Aftermarket Tennant 9015391
Machine Fitment	Tennant T500/T500e, Nobles Speed Scrub SS500, Tennant S880, Tennant T380, Tennant T2, Tennant T3, Tennant T300/T300e, Nobles SS3, Nobles SS300
Description	Offboard charger comes out of the box with the SB50 grey Anderson Connector pre-assembled, there is also a SB50 red Anderson Connector included in the box as well. Charger comes pre-programmed at "wet" battery setting, but it is the customer's responsibility to verify their machine's battery type before setting the charger profile on the charger itself.
AC Input	Input Voltage (auto-sensing): 100-240 VAC, 50/60 Hz Input Current Max: 11 Amps Single Phase Input Receptacle: IEC C14
DC Output	Output Voltage - Nominal: 24 VDC Output Voltage - Flooded: 29.7 VDC Output Voltage - AGM / Gel: 28.8 VDC Float Voltage: 26.5 VDC Max DC Current: 20 Amps Battery Type: Lead Acid, AGM, Gel 3 Stage Charging Profile: CC/CV/Float Load Sensing, Minimum Voltage: 8 Volts
Features	Charger Ships with 6 foot lead with SB 50 Connector Selectable Charging Profile: Flooded, AGM or GEL Low start voltage 4 volts Continuous 100% duty cycle Optimal 3 Step Charging Built-in Mode Indicators Demand Sensing Reverse Polarity Protection Over Voltage Protected Short Circuit Protection Overload Protection Thermal Protection 2 Year Warranty
